Advantage:
Adopt UV curing lamp, fast drying, reduce waiting time, greatly shorten coating time,
It can improve the surface hardness of the coating and brighten the color. It can also be directly matched with the coating machine. Eliminate the hassle of handling.
Features:
1. Control mode: board + switch control + stepless adjustment
1. Simple operation.
2. UV light supply system
1. The light is stable and reliable. 2. Independent light module.
3. Transportation system
1. The chain transmission runs at the same speed, fully closed cycle control,
2. High-strength guide rail design, small thermal deformation and high precision;
3. The width adjustment of the guide rail adopts manual width adjustment and panel control, which is convenient and easy to use;
4. The new guide rail suspension width adjustment system makes the adjustment more convenient and ensures that the guide rail does not deform;
5 With independent exhaust fan, three independent temperature zones are allocated (storage area + solidification area + cooling area)
6. Drying at high temperature will not damage the board
Specs
Model SM-UV106CM
Type Online
Maximum board width 450MM
Performance storage area + solidification area + cooling area
Control mode switch control
Transmission direction L→R
Width adjustment range 50～450MM
Rail load (including clamps) 5.8 kg
Rail fixing method front
Conveyor belt height 900±20MM
Conveyor belt speed 700～2000mm/min
Heating time 2min
Power supply 380V
Weight 200KG
