SCN250 90-degree PCB Turning Conveyor – Material Handling Equipment

SCN250 90-degree PCB turning conveyor board handing system conveyor serial

The SCN250 90-degree PCB Turning Conveyor is a high-quality product designed to optimize your PCB assembly process. This conveyor is specifically engineered to turn PCBs at a 90-degree angle, allowing for efficient and streamlined production. With its durable construction and reliable performance, the SCN250 is an essential tool for any electronics manufacturer. Our team has carefully crafted this product to meet the highest standards of quality and functionality, ensuring that it will provide long-lasting value for your business. Trust the SCN250 90-degree PCB Turning Conveyor to help you achieve your production goals and take your operations to the next level.

More pictures please click SMT PCB board conveyor

We design and manufacture Auto Insertion and SMT Machines for Electronic PCB Assembly.

Specialize in Auto Insertion machine and SMT equipments, providing spare parts, sub-assembly, retrofit kit, repair kit, upgrading, training,overhaul service.

Description

This unit is used to redirect PCBs in a production line, usually used for two combined one assembly line, L or U type SMT assembly line.

Features

User-friendly ‘soft-touch’ LED control membrane control panel
Enclosed design with built-in torque limiter ensures the highest level of safety
The top cover can be opened for easy access to hardware during maintenance
Parallel and smooth width adjustment (leadscrew)
Steady and precise scaling (retractable motor)
Minimize transmission clearance between conveyor
Different sizes available upon request
PCB traffic flows can be customized
SMEMA compatible

Technical specifications

Transport height:900mm ±20mm or specify
Transfer direction:L to R or specify R to L
Belt type: ESD belt (round belt)
Cycle time: 15 seconds approx.
Power supply: AC 110 Volts Or 220 Volts; Single Phase
Power consumption:150VA max. or specify
PCB Thickness：0.6~4 mm
