Description
We provide design and manufacture Wave Solder Pallet/Reflow Fixture:
- 24 hours lead time
- price from $50.00
- customized
Name : PCB solder paller High Operating Temperature Durostone plastic Sheet
Size: 1000*1200mm,1000*2000mm
Thickness: 3-30mm
Type: PCB durostone plate
Description
Durostone is a glass fiber compound which designed to satisfy different needs on painting of PCB ,and its a heavyduty glass fiber reinforced plastic which offers extreme strength and excellent electrical, thermal and chemical properties. Durostone is manufactured by using Polyester, Vinylester, Epoxid- and modified Epoxy resins combined with glass fibers.
It can keep it’s mechanical strength,smoothness and original color when continuously used under the temperature of 280°c (max. working temperature below 385 degree 10~20sec). It’s applicable in ROHS applicance production line under high temperature continuously.this can improve PCB quality during the wave soldering to prevent pollution of gold_finger or contract hole caused by human contact.
Sepcification for wave solder pallets:
Technical Data | CHP760 | CAS761 | CAG762 |
Grade | Standard | Anti-Static | Anti-static(Optical) |
Colour | Blue | Black | Grey |
Density(g/mm3) | 1.85 | 1.85 | 1.85 |
Standard OperationTemperature | 260 | 260 | 260 |
Maximum Operation Temperature(C) | 350 | 350 | 350 |
Surface Resistivity (ohms) | — | 105-108 | 105-108 |
Sheet Size(mm) | 2440×1220 | 2440×1220 | 2440×1220 |
Tickness/weight(mm/kg) | 3/17, 4/22, 5/28, 6/33, 8/44, 10/55, 12/66 |
Features:
1,Used materials imported synthetic stone materials, quality imported bakelite, glass fiber, alloy
2,Reflow soldering printed circuit board tooling
3,Decrease deformation of the substrate caused by the tin stove and electrostatic breakdown
4,Applicable substrate shape
5,Loading multiple PCB production line, saving manpower and after welding, improve productivity
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Plastlist wave solder pallets are lead to overall process efficiency by:
– Reducing set-up time
– Wave solder complex, double-sided circuit board assemblies
– Eliminating expensive, and labor-intensive masking
– Providing safe, easy, ergonomic handling of PCB
– Providing thermal protection for printed circuit board areas that are heat sensitive
– Processing multiple boards at the same time
– Reducing bridging and skipping solder defects
– Increasing production and enhance automated assembly
– Ensuring higher quality, repeatable process results
– High temperature resistance to endure repeated cycles through the reflow
– Dimensional stability to ensure board alignment is consistent
– Chemical resistance
– Very low moisture absorption
– Reduces solder defects
– Low heat absorption
We also provide a wide range of manufacturing solution for wave solder pallets by customer’s customized demand.
Universal Adjustable Solder Pallet
![]() |
![]() |
![]() |
![]() |
Universal wave solder pallets are designed to support a PCB that would otherwise be unable to be processed through wave soldering. Central bars easily adjust for PCB width.
![]() |
Block Tin Bar |
![]() |
Common Hold Downs for Solder Pallet/ Carrier Accessories |
![]() |
5# Round Feet Hold Downs for Solder Pallet Accessories |
![]() |
4# Pointed Feet Hold Downs for Solder Pallet Accessories |
![]() |
3# Wide Feet Hold Downs for Solder Pallet Accessories |
![]() |
13# Double Side Hold Downs for Solder Pallet Accessories |
![]() |
7# Double Side Hold Downs for Solder Pallet Accessories |
![]() |
16# Press Components Hold Downs for Fixtures Accessories |
![]() |
17# Press Components Hold Downs for Fixtures Accessories |
![]() |
18# Anti-floated High Hold Downs for Solder Pallet/ Carriers |
![]() |
20# Press Components Briquette for Fixtures Accessories |
![]() |
22# Cover Plate Buckle for Solder Pallet/ Carriers |
